ENCODER HD 8X NETUP

Name: Encoder HD 8X NETUP
Brand: NETUP- NGA

Mã sản phẩm : ENCODER HD 8X

Xuất xứ : NETUP- NGA

Bảo hành : 12 Tháng

ENCODER HD 8X NETUP

CHI TIẾT
THÔNG SỐ KỸ THUẬT
DOWNLOAD

NetUP HDMI Encoder 8x is a professional HDMI H.264 encoder. It is equipped with 8 HDMI inputs and IP output, and also 1 ASI input for re-mux. The encoder supports MPEG-4 AVC/H.264 high profile & main profile. It is perfect for encoding signal from DVB receivers, DVD & Blu-ray players.

Thông số kỹ thuật:

Physical & Power	Inputs/Outputs
standard rack-mount case for 19" telecom rack	8 x HDMI inputs
height: 1U	1 x ASI input, BNC
power supply: AC 100V-220V±10%, 50/60Hz	1 x ASI output
consumption: 25W	1 x IP output
temperature: 0~45℃(work), -20~80℃ (Storage)	Control & Administration
dimensions (WHD): 440 x 44.5 x4 10 mm	front panel LCD
weight: 4 kg	keyboard support
Performance	network management (SNMP)
MPEG-4 AVC/H.264 encoding	Package
Supports following resolutions:	type: carton box
1920×1080_60P, 1920×1080_50P	dimensions: 600 x 600 x 300 mm
1920×1080_60i, 1920×1080_50i	weight: 7 kg
1280×720_60P, 1280×720 _50P
720×576_50i, 720×480_60i
Supports multiplexing function
0.8 Mbps - 19 Mbps each channel

Physical & Power	Inputs/Outputs
standard rack-mount case for 19" telecom rack	8 x HDMI inputs
height: 1U	1 x ASI input, BNC
power supply: AC 100V-220V±10%, 50/60Hz	1 x ASI output
consumption: 25W	1 x IP output
temperature: 0~45℃(work), -20~80℃ (Storage)	Control & Administration
dimensions (WHD): 440 x 44.5 x4 10 mm	front panel LCD
weight: 4 kg	keyboard support
Performance	network management (SNMP)
MPEG-4 AVC/H.264 encoding	Package
Supports following resolutions:	type: carton box
1920×1080_60P, 1920×1080_50P	dimensions: 600 x 600 x 300 mm
1920×1080_60i, 1920×1080_50i	weight: 7 kg
1280×720_60P, 1280×720 _50P
720×576_50i, 720×480_60i
Supports multiplexing function
0.8 Mbps - 19 Mbps each channel
