KHUẾCH ĐẠI QUANG VTS HA-5100

KHUẾCH ĐẠI QUANG  VTS HA-5100

• 1540~1563nm operating bandwidth
• Low noise, high output, high reliability
• APC、ACC、ATC controlled selection(HA5100/P)
• Powerful RS232 supervisory instruction
• Three exterior option: 1U (19” stander), 3D (12.4”, 3U,Desk-type) and modulator
• 1U and 3D exterior, offering status appearance anddiagnosing fault with LCD, standard RS232 communication interface, SNMP network management function
• Application of 3D models to adapt to laboratory
• Excellent P/P ratio in area
• AM CATV
• Digital CATV
• DBS & MMDS
• FTTP
• FTTx PON
• Laboratory application

Performance Index Supplement
Min. Typ. Max.
Optical
feature
Operating wavelength (nm) 1540   1563 CATV
Input power (dBm) -10 .+3 55
Maximum output (dBm) .+10   .+10 Pin=0dBm
Output power (dBm) -6   .+26 HA-5100/P
Number of output ports 1   0 SC/APC
1   8 LC/APC
Difference of each (dBm) .-0.5   16
Noise figure (dB)     .+0.05 HA-5100-26
Polarization (dB)     6.3
Polarization (dB)     0.4
Polarization mode (ps)     0.5
Input/output isolation (dB) 30
Pump power leakage (dBm)     .-30
Echo loss (dB) 55     APC
General
feature
SNMP network RJ45
Serial interface RS232
Power supply (V) 90   265 220VAC
30   72 -48VDC
23   25 +24VDC
Power consume (W)     50
Operating temp (°C) -5   65
Storage temp. (°C) -40   80
Operating relative (%) 5   95
Size (W)×(D)×(H) (") 19×14.5×1.75 1RU (19”)
(") 12.4×15.4×5.25 3D (12.4”, desk-type)
(mm) 150×125×22 Modulator
PRODUCT SERIES
Model Output power Max (dBm)
Pin=0dBm
Noise figure (dB)
Pin=0dBm
Input power range (dBm) Function
Min. Typ. Max.
HA-5113/ON ≥13 4.0 -10 0 10 With SNMP network
 management,
 output power is not
adjustable
HA-5114/ON ≥14 4.1
HA-5115/ON ≥15 4.2
HA-5116/ON ≥16 4.3
HA-5117/ON ≥17 4.5
HA-5118/ON ≥18 4.8
HA-5119/ON ≥19 5.0
HA-5120/ON ≥20 5.3
HA-5121/ON ≥21 5.5
HA-5122/ON ≥22 5.8
HA-5123/ON ≥23 6.0
HA-124/ON ≥24 6.3
HA-5125/ON ≥25 6.5
HA-5126/ON ≥26 6.8
HA-5120/PN ≥20 5.3 -10 0 10 With SNMP
network management,
the output optical
 power adjustable
 0~ -6dB
HA-5121/PN ≥21 5.5
HA-5122/PN ≥22 5.8
HA-5123/PN ≥23 6.0
HA-5124/PN ≥24 6.3
HA-5125/PN ≥25 6.5
HA-5126/PN ≥26 6.8
