MÁY THU QUANG - NODE QUANG WINERSAT WOR-100

WOR-100

WINERSAT- TAIWAN

12 Tháng

MÁY THU QUANG - NODE QUANG WINERSAT WOR-100

MÁY THU QUANG WINERSAT WOR-100

FEATURES

 Optional receiving range: -2 ~ -10dBm, -2 ~ -12dBm -2 ~ -15dBm, -2 ~ -18dBm

 Optical AGC

 Optional RF output level: H: 75~80dBuV, M: 70~75dBuV, L: 65~70dBuV

 Power supply and optical power LED indicator on panel

 Unique heat dissipation design to ensure a stable working

 Compact size for convenient installation

Specifications

Optical Spec.
Wavelength 1210nm—1610nm
Input Optical Power -9~+2 dBm
AGC Range -6~+2 dBm
Led Indicator ≥ -9dBm Green, ≤ -9dBm Red
RF Spec.
Bandwidth 85-1000 MHz
Flatness ≤±1 dB
Return Loss ≥16 dB
Slope 5±1 dB
RF Output Level 80-85 dBuV, 105MHz —1000MHz
C/N ≥50 dB, Optical Input @ -1dBm, 78 Channels
C/CTB ≥65 dB, Optical Input @ -1dBm, 78 Channels
C/CSO ≥62 dB, Optical Input @ -1dBm, 78 Channels
Impedance 75Ω
Return Path Optical Spec
Wavelength 1550 or 1310nm
Optical Output Power 1 or 2 mW
Laser Type DFB or FP
Return Path RF Spec
Bandwidth 5-65 MHz
Flatness ≤±1 dB
Return Loss ≥16 dB
Input RF Level 80 dBuV
Input RF Range 65-95 dBuV
NPR Dynamic Range 20dB (FP Laser, NPR≥30dB); 25dB (DFB Laser, NPR≥30dB)
Other Spec.
Input Voltage 12-18 VDC
Power Consumption
Working Temp. -20~ +55℃
Optical Connector SC/APC
RF Connector F-Type
Surge Protection 6 KV
Dimensions(L×W×H) 128×78×31mm
*Model Number 01 - Without return transmitter; only forward receiver
02 - With return transmitter; FP Laser Type
